Navistar INTERNATIONAL DT 466 Service Manual

FUEL SYSTEM 355
Figure 560 Installing the high-pressure oil rail
assembly
8. Lift high-pressure oil rail assembly up and place
onto engine. Align injector oil supply nozzles with
oil inlet adapters.
H08090
1
3
4
7
8
11
12
2
5
6
9
10
Figure 561 High-pressure oil rail bolt torque sequence (typical)
9. Install and hand tighten 12 bolts (M8 x 90) to
secure the high-pressure oil rail to the cylinder
head. Tighten bolts to the special torque value
(Table 47) and in the circular pattern, beginning
from the center.
EGES-265-2
Read all safety instructions in the "Safety Information" section of this manual before doing any procedures.
Follow all warnings, cautions, and notes.
© 2009 Navistar, Inc.
