LB9 User’s Guide 1265/1523
11.4.4.3 RADIUS Named Server Status
Use this panel to view the information about the RADIUS servers configured on the system.
Non-Configurable Data
Current - Indicates whether the selected RADIUS server is the current server (True) or a backup
server (False). If more than one RADIUS server is configured with the same name, the switch
selects one of the servers to be the current server from the group of servers with the same
name.When the switch sends a RADIUS request to the named server, the request is directed to the
server selected as the current server. Initially the primary server is selected as the current server. If
the primary server fails, one of the other servers becomes the current server. If the primary server is
not configured, the current server is the most recently configured RADIUS server.
RADIUS Server IP Address - Shows the IP address of the RADIUS server.
RADIUS Server Name - Shows the RADIUS server name.Multiple RADIUS servers can have the
same name. In this case, RADIUS clients can use RADIUS servers with the same name as backups
for each other.
Port Number - Identifies the authentication port the server uses to verify the RADIUS server
authentication. The port is a UDP port.
Server Type - Shows whether the server is a Primary or Secondary server.
Secret Configured - Indicates whether the shared secret for this server has been configured.
Command Buttons
Refresh - Update the information on the page.
