LB9 User’s Guide 58/1523
6.2 Device Configuration Commands
6.2.1 Interface
6.2.1.1 show interface status
This command displays the Port monitoring information for the system.
<slot/port> - is the desired interface number.
<loopback-id> - Disaplys information for the loopback interfaces. The range of the loopback ID is 0
to 7.
<portchannel-id> - Displays information for the port-channel interfaces. The range of the
port-channel ID is 1 to 64.
<tunnel-id> - Displays information for the tunnel interfaces. The range of the tunnel ID is 0 to 7.
<vlan-id> - Displays information for the vlan interfaces. The range of the VLAN ID is 1 to 4093.
no parameter - Displays information for all interfaces.
Default Setting
None
Command Mode
Privileged Exec
Display Message
Intf: The physical slot and physical port.
Type: If not blank, this field indicates that this port is a special type of port. The possible values are:
Source: This port is a monitoring port.
PC Mbr: This port is a member of a port-channel (LAG).
Dest: This port is a probe port.
Admin Mode: Selects the Port control administration state. The port must be enabled in order for it
to be allowed into the network. It may be enabled or disabled. The factory default is enabled.
Physical Mode: Selects the desired port speed and duplex mode. If auto-negotiation support is
selected, then the duplex mode and speed will be set from the auto-negotiation process. Note that
the port's maximum capability (full duplex 100M) will be advertised. Otherwise, this object will
determine the port's duplex mode and transmission rate. The factory default is Auto.
Physical Status: Indicates the port speed and duplex mode.
