LB9 User’s Guide 1465/1523
11.8.7 Managing PIM Protocol
11.8.7.1 Configuring Global Configuration
Selection Criteria
PIM Protocol Type - The protocol variant of PIM that is to be enabled/disabled i.e, Sparse mode or
Dense mode.
Configurable Data
Admin Mode - Select enable or disable from the pulldown menu to set the administrative status of
PIM-DM in the router. The default is disabled.
Data Threshold Rate (kbps) - Enter the rate in K bits/second above which the last-hop router will
switch to a source-specific shortest path tree. This field is applicable only for PIMSM. The valid
values are from (0 to 2000). The default value is 0. NOTE: Non-Zero Data Threshold Rate is
currently not supported. Switch on First Packet policy is only supported.
Command Buttons
Submit - Send the updated configuration to the router. Configuration changes take effect
immediately. These changes will not be retained across a power cycle unless a save is performed.
Refresh - Refresh the data on the screen with the present state of the data in the switch.
