LB9 User’s Guide 182/1523
6.2.13 Port Mirror
6.2.13.1 show port-monitor session
This command displays the Port monitoring information for the specified session.
<session-id> - session ID. The range of session ID is 1 to 4.
Default Setting
None
Command Mode
Privileged Exec
Display Message
Session ID: indicates the session ID.
Admin Mode: indicates whether the Port Monitoring feature is enabled or disabled. The possible
values are enabled and disabled.
Dest. Port: is the slot/port that is configured as the probe port. If this value has not been configured,
'Not Configured' will be displayed.
Source Port: is the slot/port that is configured as the monitored port. If this value has not been
configured, 'Not Configured' will be displayed.
Type: Direction in which source port configured for port mirroring.Types are tx for transmitted
packets and rx for receiving packets.
