LB9 User’s Guide 139/1523
6.2.8 MLD Snooping
6.2.8.1 show ipv6 mld snooping
The user can go to the CLI Privilege Exec to get all of mld snooping information, use the show ip mld
snooping Privilege command.
<slot/port> - Interface number.
<vlan-id> - VLAN ID (Range: 1 – 4093).
<portchannel-id> - Port-channel interface number. The range of port-channel ID is 1 to 64.
Default Setting
None
Command Mode
Privileged Exec
User Exec
Display Message
W
hen the optional arguments <sl
ot/port>, <p
ortchannel-
id> or <vlan-i
d> are not u
sed, the comm
and
displays the following information.
Admin Mode: Indicates whether or not MLD Snooping is active on the switch.
Interfaces Enabled for MLD Snooping: Interfaces on which MLD Snooping is enabled.
Multicast Control Frame Count: Displays the number of MLD Control frames that are processed by
the CPU.
VLANs Enabled for MLD Snooping: VLANs on which MLD Snooping is enabled.
When you specify the <slot/port> or <portchannel-id> values, the following information displays.
MLD Snooping Admin Mode: Indicates whether MLD Snooping is active on the interface.
Fast Leave Mode: Indicates whether MLD Snooping Fast Leave is active on the interface.
Group Membership Interval: Shows the amount of time in seconds that a switch will wait for a
report from a particular group on a particular interface, which is participating on the interface, before
deleting the interface from the entry. This value may be configured.
Multicast Router Expiry Time: Displays the amount of time to wait before removing an interface
that is participating on the interface from the list of interfaces with multicast routers attached. The
interface is removed if a query is not received. This value may be configured.
When you specify a value for <vlan-id>, the following information appears.
