LB9 User’s Guide 1455/1523
11.8.6 Managing IGMP
11.8.6.1 Configuring IGMP Global Configuration
Configurable Data
Admin Mode - Select enable or disable from the pull down menu to set the administrative status of
IGMP in the router to active or inactive. The default is disable.
Command Buttons
Submit - Update the switch with the values on the screen. If you want the switch to retain the new
values across a power cycle you must perform a save.
11.8.6.2 Configuring IGMP Rouing interface
Selection Criteria
Interface - Select the slot and port for which data is to be displayed or configured from the pull down
menu. Slot 0 is the base unit. You must have configured at least one router interface before
configuring or displaying data for an IGMP interface, otherwise an error message will be displayed.
Configurable Data
