LB9 User’s Guide 604/1523
6.20.5 Show Commands
The 'show' command set is used in DiffServ to display configuration and status information for:
ï‚· Classes
ï‚· Policies
ï‚· Services
This information can be displayed in either summary or detailed formats. The status information is only
shown when the DiffServ administrative mode is enabled; it is suppressed otherwise. There is also a
'show' command for general DiffServ information that is available at any time.
6.20.5.1 show class-map
This command displays all configuration information for the specified class.
<classname> is the name of an existing DiffServ class.
Default Setting
None
Command Mode
Privileged Exec
User Exec
Display Message
Class Name: The name of this class.
Class Type: The class type (all, any, or acl) indicating how the match criteria are evaluated for this
class. A class type of all means every match criterion defined for the class is evaluated
simultaneously they must all be true to indicate a class match. For a type of any each match criterion
is evaluated sequentially and only one need be true to indicate a class match. Class type acl rules
are evaluated in a hybrid manner, with those derived from each ACL Rule grouped and evaluated
simultaneously, while each such grouping is evaluated sequentially.
L3 Proto: The Layer 3 protocol for this class. Possible values are IPv4 and IPv6.
Match Criteria: The Match Criteria fields will only be displayed if they have been configured. They
will be displayed in the order entered by the user. These are evaluated in accordance with the class
type. The possible Match Criteria fields are: Class of Service, Destination IP Address, Destination
Layer 4 Port, Destination MAC Address, Every, IP DSCP, IP Precedence, IP TOS, Protocol
