UANTA COMPUTER INC.
Layer 2/3/4 Managed Switch
_____________________________________________________________________________
LB9 User’s Guide 1284/1523
Enter an integer from 0 to 63. The IPv6 DSCP is selected by possibly selection one of the DSCP
keyword from a dropdown box. If a value is to be selected by specifying its numeric value, then
select the 'Other' option in the dropdown box and a text box will appear where the numeric value of
the DSCP can be entered.
Command Buttons
Configure - Configure the corresponding match criteria for the selected rule.
Delete - Remove the currently selected Rule from the selected ACL. These changes will not be
retained across a power cycle unless a save configuration is performed.
11.4.7.8 IPv6 ACL Rule status Summary Page
Non-Configurable Data
IPv6 ACL Name – IPv6 ACL identifier.
Rule - Rule number.
Time Range Name - Indicates the name of the time range associated to the rule.
Rule Status - Indicates the status of the rule. Rule status is shown only for the rules which are time
based. For non time based rules, rule status is considered to be active.
Command Buttons
Refresh - Refresh the data on the screen with the present state of the data in the switch.
