LB9 User’s Guide 1326/1523
Submit - Send the updated configuration to the switch. Configuration changes take effect
immediately. These changes will not be retained across a power cycle unless a save is performed.
Restore Defaults - Restores default settings.
11.5.5.2 Managing DSCP Mapping Configuration Page
Selection Criteria
Interface - Specifies all CoS configurable interfaces. The option "Global" represents the most recent
global configuration settings.
Configurable Data
IP DSCP Value Traffic Class - Specify which internal traffic class to map the corresponding IP
DSCP value. Valid Range is (0 to 7) .
Non-Configurable Data
IP DSCP Value - Specify the IP DiffServ Code Point (DSCP) Value.
Command Buttons
