LB9 User’s Guide 1378/1523
11.6.6.4 Configuring Route Redistribution Configuration
This screen can be used to configure the RIP Route Redistribution parameters. The allowable values for
each field are displayed next to the field. If any invalid values are entered, an alert message will be
displayed with the list of all the valid values.
Configurable Data
Configured Source - This select box is a dynamic selector and would be populated by only those
Source Routes that have already been configured for redistribute by RIP. However, the topmost
option in the select box would be "Create", and this allows the user to configure another, among the
Available Source Routes. The valid values are 'Static', 'Connected', 'OSPF' and 'Create'.
Available Source - This select box is a dynamic selector and would be populated by only those
Source Routes that have not previously been configured for redistribution by RIP. This select box
would appear only if the user selects "Create" option as Configured Source. The valid values are
'Static', 'Connected', and 'OSPF'.
Metric- Sets the metric value to be used as the metric of redistributed routes. This field displays the
metric if the source was pre-configured and can be modified. The valid values are (1 to 15)
Match - One or more of these checkboxes must be selected to set the type of OSPF routes to be
redistributed. This field would appear only if Source is "OSPF". This field displays the configured
match options if "OSPF" was pre-configured and can be modified.
