LB9 User’s Guide 159/1523
This command displays an overview of all port-channels (LAGs) on the switch.
Default Setting
None
Command Mode
Privileged Exec
Display Message
Channel ID: The ID of this port-channel.
Channel Name: The name of this port-channel (LAG). You may enter any string of up to 15
alphanumeric characters.
Link: Indicates whether the Link is up or down.
Admin Mode: May be enabled or disabled. The factory default is enabled.
Type: This field displays the status designating whether a particular port-channel (LAG) is statically
or dynamically maintained. The possible values of this field are Static, indicating that the
port-channel is statically maintained; and Dynamic, indicating that the port-channel is dynamically
maintained.
Mbr Ports: A listing of the ports that are members of this port-channel (LAG), in slot/port notation.
There can be a maximum of eight ports assigned to a given port-channel (LAG).
Device Timeout: Thie field displays the device timout value of actor and parter. The value of device
timeout should be short(1 second) or long(30 seconds).
Port Speed: Speed of the port-channel port.
Port Active: This field lists the ports that are actively participating in the port-channel (LAG).
