LB9 User’s Guide 79/1523
6.2.2.3 show mac-addr-table interface
This command displays the forwarding database entries. The user can search FDB table by using
interface number <slot/port>.
<slot/port> - Specifies the desired interface.
<portchannel-id> - Specifies the desired port-channel interface. The range of port-channel ID is 1 to
64.
<vlan-id> - Specifies the desired VLAN interface. The range of VLAN ID is 1 to 4093.
Default Setting
None
Command Mode
Privileged Exec
Display Message
Mac Address: A unicast MAC address for which the switch has forwarding and/or filtering
information. The format is 6 or 8 two-digit hexadecimal numbers that are separated by colons, for
example 01:23:45:67:89:AB. In an IVL system the MAC address will be displayed as 8 bytes. In an
SVL system, the MAC address will be displayed as 6 bytes. Note: This software version only
supports IVL systems.
VLAN ID: The vlan id of that mac address.
Status: The status of this entry.
The meanings of the values are:
Static: The value of the corresponding instance was added by the system or a user when a
static MAC filter was defined. It cannot be relearned.
Learned: The value of the corresponding instance was learned by observing the source MAC
addresses of incoming traffic, and is currently in use.
Management: The value of the corresponding instance (system MAC address) is also the value
of an existing instance of dot1dStaticAddress. It is identified with interface 3/1 and is currently
used when enabling VLANs for routing.
Self: The value of the corresponding instance is the address of one of the switch’s physical
interfaces (the system’s own MAC address).
GMRP Learned: The value of the corresponding instance was learned via GMRP and applies to
Multicast.
Other: The value of the corresponding instance does not fall into one of the other categories.
