Table 6-1: Provided XML files
Path XML file name Displayed standard character-
istics*
cdma2000\DL default0.xml CDMA2000 BC0 DL
default1.xml CDMA2000 BC1 DL
cdma2000\UL default0.xml CDMA2000 BC0 UL
default1.xml CDMA2000 BC1 UL
WCDMA\3GPP\DL PowerClass_31_39.xml W-CDMA 3GPP (31,39)dBm DL
PowerClass_39_43.xml W-CDMA 3GPP (39,43)dBm DL
PowerClass_43_INF.xml W-CDMA 3GPP (43,INF)dBm
DL
PowerClass_negINF_31.xml W-CDMA 3GPP (-INF,31)dBm
DL
WIBRO\DL PowerClass_29_40.xml WiBro TTA (29,40)dBm DL
PowerClass_40_INF.xml WiBro TTA (40,INF)dBm DL
PowerClass_negINF_29.xml WiBro TTA (-INF,29)dBm DL
WIBRO\UL PowerClass_23_INF.xml WiBro TTA (23,INF)dBm UL
PowerClass_negINF_23.xml WiBro TTA (23,INF)dBm UL
WIMAX\DL\ETSI\…MHz (1.75
MHz, 2.00 MHz, 3.5 MHz, 7.00
MHz, 14.00 MHz, 28 MHz)
System_Type_E.xml WIMAX System Type E DL
System_Type_F.xml WIMAX System Type F DL
System_Type_G.xml WIMAX System Type G DL
WIMAX\DL\IEEE 10MHz.xml WIMAX 10MHz DL
20MHz.xml WIMAX 20MHz DL
WIMAX\UL\ETSI…MHz (1.75
MHz, 2.00 MHz, 3.5 MHz, 7.00
MHz, 14.00 MHz, 28 MHz)
System_Type_E.xml WIMAX System Type E UL
System_Type_F.xml WIMAX System Type F UL
System_Type_G.xml WIMAX System Type G UL
WIMAX\UL\IEEE 10MHz.xml WIMAX 10MHz UL
20MHz.xml WIMAX 20MHz UL
WLAN\802_11_TURBO ETSI.xml IEEE 802.11
IEEE.xml IEEE 802.11
WLAN\802_11a ETSI.xml IEEE 802.11a
IEEE.xml IEEE 802.11a
WLAN\802_11b IEEE.xml IEEE 802.11b
WLAN\802_11j_10MHz ETSI.xml IEEE.802.11j
