R&S ESR Series User Manual

Spectrum Measurements
R&S
®
ESR
278User Manual 1175.7068.02 ─ 12
</Limit>
<RBW Bandwidth=""Bandwidth"" Type=""FilterType""/>
<VBW Bandwidth=""Bandwidth""/>
<Detector>"Detector"</Detector>
<Sweep Mode=""SweepMode"" Time=""SweepTime""/>
<Amplitude>
<ReferenceLevel Unit=""dBm"" Value=""Value""/>
<RFAttenuation Mode=""Auto"" Unit=""dB"" Value=""Value""/>
<Preamplifier State=""State""/>
</Amplitude>
</Range>
Table 6-2: Attributes and child nodes of the BaseFormat element
Child Node Attribute Value Parameter Description Mand.
FileFormatVersion 1.0.0.0 Yes
Date YYYY-MM-DD
HH:MM:SS
Date in ISO 8601 format No
Name <string> Name of the standard Yes
Instrument Type FSL Name of the instrument No
Application SA | K72 | K82 Name of the application No
LinkDirection Name Downlink | Uplink |
None
Yes
ShortName DL | UL No
Reference-
Power
Yes
Method TX Channel Power |
TX Channel Peak
Power
Yes
Reference-
Channel
<string> No
Table 6-3: Attributes and child nodes of the PowerClass element
Child Node Attribute Value Parameter Description Mand.
StartPower Value <power in dBm> The start power must be equal
to the stop power of the previ-
ous power class. The Start-
Power value of the first range
is -200
Yes
Unit dBm Yes
InclusiveFlag true Yes
StopPower Value <power in dBm> The stop power must be equal
to the start power of the next
power class. The StopPower
value of the last range is 200
Yes
Unit dBm
Measurements
