R&S ESR Series User Manual

Spectrum Measurements
R&S
®
ESR
401User Manual 1175.7068.02 ─ 12
Trace Mode;CLR/WRITE; Trace mode
Trace 1:
X-Unit;Hz; Unit of the x-axis
Detector;MAX PEAK; Detector type
Values;1343; Number of measurement points
Y-Unit;Hz; Unit of the y-axis
Trace 2:
150000.000000;3.541122;
154500.000000;5.776306;[...]
String of results
Data section (traces)
(…)
Type; <instrument_model>; Instrument model
Version;1.00; Firmware version
Date;01. Jan 3000; Date of data set storage
Mode;Analyzer; Application
Center Freq;100000000.000000; Center frequency
Freq Offset;0.000000;Hz; Frequency offset
Span;10000000000.000000;Hz;
Start;150000.000000:Hz;
Stop;2500000.000000;Hz;
Ref Position;100.000000;%; Reference position
Header
Blue font: Information provided when you export a single trace
Green font: Information provided when you export all traces
Black font: Information provided regardless of the export mode
Frequency span
Start frequency
Stop frequency
Ref Level;97.000000;dBµV;
Level Offset;0.000000;Hz;
Reference level
Reference level offset
X-Axis;LIN; Scale of the x-axis
Trace mode;CLR/WRITE; Trace mode
SWT;0.002000;s; Sweep time
VBW;300000.000000;Hz; Video bandwidth
Y-Axis;LOG; Scale of the y-axis
Level Range;100.000000;dB; Range of the y-axis
Rf Att;10.000000;dB; RF attenuation
RBW;3000000.000000;Hz; Resolution bandwidth
Detector;AUTOPEAK; Detector type
Sweep Count;0; Sweep / average count
Preamplifier;OFF; State of the preamplifier
Y-Unit;Hz; Unit of the y-axis
X-Unit;Hz; Unit of the x-axis
Transducer;OFF; Transducer information
