Generator Interface Type Generator Min
Freq
Generator Max
Freq
Generator Min
Power
dBm
Generator Max
Power
dBm
SMC100A3 TTL 9 kHz 3.2 GHz -145 +30
SME02 TTL 5 kHz 1.5 GHz -144 +16
SME03 TTL 5 kHz 3.0 GHz -144 +16
SME06 TTL 5 kHz 6.0 GHz -144 +16
SMG GPIB 100 kHz 1.0 GHz -137 +13
SMGL GPIB 9 kHz 1.0 GHz -118 +30
SMGU GPIB 100 kHz 2.16 GHz -140 +13
SMH GPIB 100 kHz 2.0 GHz -140 +13
SMHU GPIB 100 kHz 4.32 GHz -140 +13
SMIQ02B TTL 300 kHz 2.2 GHz -144 +13
SMIQ02E GPIB 300 kHz 2.2 GHz -144 +13
SMIQ03B TTL 300 kHz 3.3 GHz -144 +13
SMIQ03E GPIB 300 kHz 3.3 GHz -144 +13
SMIQ04B TTL 300 kHz 4.4 GHz -144 +10
SMIQ06B TTL 300 kHz 6.4 GHz -144 +10
SML01 GPIB 9 kHz 1.1 GHz -140 +13
SML02 GPIB 9 kHz 2.2 GHz -140 +13
SML03 GPIB 9 kHz 3.3 GHz -140 +13
SMR20 TTL 1 GHz 20 GHz
-130
2)
+11
2)
SMR20B11
1)
TTL 10 MHz 20 GHz
-130
2)
+13
2)
SMR27 TTL 1 GHz 27 GHz
-130
2)
+11
2)
SMR27B11
1)
TTL 10 MHz 27 GHz
-130
2)
+12
2)
SMR30 TTL 1 GHz 30 GHz
-130
2)
+11
2)
SMR30B11
1)
TTL 10 MHz 30 GHz
-130
2)
+12
2)
SMR40 TTL 1 GHz 40 GHz
-130
2)
+9
2)
SMR40B11
1)
TTL 10 MHz 40 GHz
-130
2)
+12
2)
SMR50 TTL 1 GHz 50 GHz
-130
2)
+9
2)
1) Requires the option SMR-B11 to be fitted.
2) Maximum/minimum power depends on presence of Option SMR-B15/-B17 and set frequency range. For
more details see SMR data sheet.
3) Maximum/minimum power depends on presence of Option SMP-B15/-B17 and set frequency range. For
more details see SMP data sheet.
4) Requires firmware version V3.20.200 or higher on the signal generator
Connecting External Tracking Generators
