R&S ESR Series User Manual

Tracking Generator
R&S
®
ESR
484User Manual 1175.7068.02 ─ 12
Generator Interface Type Generator Min
Freq
Generator Max
Freq
Generator Min
Power
dBm
Generator Max
Power
dBm
SMR50B11
1)
TTL 10 MHz 50 GHz
-130
2)
+12
2)
SMR60 TTL 1 GHz 60 GHz
-130
2)
+9
2)
SMR60B11
1)
TTL 10 MHz 60 GHz
-130
2)
+12
2)
SMP02 TTL 10 MHz 20 GHz
-130
3)
+17
3)
SMP03 TTL 10 MHz 27 GHz
-130
3)
+13
3)
SMP04 TTL 10 MHz 40 GHz
-130
3)
+12
3)
SMP22 TTL 10 MHz 20 GHz
-130
3)
+20
3)
SMT02 GPIB 5.0 kHz 1.5 GHz -144 +13
SMT03 GPIB 5.0 kHz 3.0 GHz -144 +13
SMT06 GPIB 5.0 kHz 6.0 GHz -144 +13
SMV03 GPIB 9 kHz 3.3 GHz -140 +13
SMU200A TTL 100 kHz 2.2 GHz -145 +13
SMU02B31 TTL 100 kHz 2.2 GHz -145 +19
SMU03 TTL 100 kHz 3 GHz -145 +13
SMU03B31 TTL 100 kHz 3 GHz -145 +19
SMU04 TTL 100 kHz 4 GHz -145 +13
SMU04B31 TTL 100 kHz 4 GHz -145 +19
SMU06 TTL 100 kHz 6 GHz -145 +13
SMU06B31 TTL 100 kHz 6 GHz -145 +19
SMW20
TTL
4)
100 kHz 20 GHz -145 +30
SMW40
TTL
4)
100 kHz 40 GHz -145 +30
SMX GPIB 100 kHz 1.0 GHz -137 +13
SMY01 GPIB 9 kHz 1.04 GHz -140 +13
SMY02 GPIB 9 kHz 2.08 GHz -140 +13
HP8340A GPIB 10 MHz 26.5 GHz -110 10
HP8648 GPIB 9 kHz 4 GHz -136 10
1) Requires the option SMR-B11 to be fitted.
2) Maximum/minimum power depends on presence of Option SMR-B15/-B17 and set frequency range. For
more details see SMR data sheet.
3) Maximum/minimum power depends on presence of Option SMP-B15/-B17 and set frequency range. For
more details see SMP data sheet.
4) Requires firmware version V3.20.200 or higher on the signal generator
Connecting External Tracking Generators
