R&S ESR Series User Manual

Remote Control
R&S
®
ESR
663User Manual 1175.7068.02 ─ 12
Suffix:
<n>
.
1...4
Selects the measurement window.
<m> 1...16
Selects the marker.
Example:
CALC:DELT2:SGR:Y:MAX
Activates and positions delta marker 2 on the peak level of the y-
axis.
Usage: Event
CALCulate<n>:DELTamarker<m>:SGRam:Y:MINimum:ABOVe
This command positions the specified delta marker on the next minimum level of the
vertical axis. The search includes only frames above the current marker position. It
does not change the horizontal position of the delta marker.
The command is available for the spectrogram.
Suffix:
<n>
.
1...4
Selects the measurement window.
<m> 1...16
Selects the marker.
Example:
CALC:DELT2:SGR:Y:MIN
Activates and positions delta marker 2 on the minimum level of
the y-axis.
CALC:DELT2:SGR:Y:MIN:ABOV
Positions delta marker 2 on the next minimum level found in the
diagram area above the current marker position.
Usage: Event
CALCulate<n>:DELTamarker<m>:SGRam:Y:MINimum:BELow
This command positions the specified delta marker on the next minimum level of the
vertical axis. The search includes only frames below the current marker position. It
does not change the horizontal position of the delta marker.
The command is available for the spectrogram.
Suffix:
<n>
.
1...4
Selects the measurement window.
<m> 1...16
Selects the marker.
Remote Commands in Receiver Mode
