Example:
CALC:DELT2:SGR:Y:MIN
Activates and positions delta marker 2 on the minimum level of
the y-axis.
CALC:DELT2:SGR:Y:MAX:BEL
Positions delta marker 2 on the next minimum level found in the
diagram area below the current marker position.
Usage: Event
CALCulate<n>:DELTamarker<m>:SGRam:Y:MINimum:NEXT
This command positions the specified delta marker on the next minimum level of the
vertical axis. The search includes frames above and below the current marker position.
It does not change the horizontal position of the delta marker.
The command is available for the spectrogram.
Suffix:
<n>
.
1...4
Selects the measurement window.
<m> 1...16
Selects the marker.
Example:
CALC:DELT2:SGR:Y:MIN
Activates and positions delta marker 2 on the minimum level of
the y-axis.
CALC:DELT2:SGR:Y:MIN:NEXT
Positions delta marker 2 on the next minimum level.
Usage: Event
CALCulate<n>:DELTamarker<m>:SGRam:Y:MINimum[:PEAK]
This command positions the specified delta marker on the current minimum level of the
vertical axis. The search is performed over all captured frames. It does not change the
horizontal position of the delta marker.
The command is available for the spectrogram.
Suffix:
<n>
.
1...4
Selects the measurement window.
<m> 1...16
Selects the marker.
Example:
CALC:DELT2:SGR:Y:MIN
Activates and positions delta marker 2 on the minimum level of
the y-axis.
Usage: Event
Remote Commands in Receiver Mode
