CALCulate<n>:LIMit<k>:ESPectrum:PCLass<Class>:COUNt <NoPowerClasses>
This command sets the number of power classes to be defined.
Suffix:
<n>
.
irrelevant
<k> irrelevant
<Class> irrelevant
Parameters:
<NoPowerClasses> 1 to 4
*RST: 1
Example:
CALC:LIM:ESP:PCL:COUN 2
Two power classes can be defined.
CALCulate<n>:LIMit<k>:ESPectrum:PCLass<Class>[:EXCLusive]
<State>
This command sets the power classes used in the spectrum emission mask measure-
ment. It is only possible to use power classes for which limits are defined. Also, either
only one power class at a time or all power classes together can be selected.
Suffix:
<n>
.
irrelevant
<k> irrelevant
<Class> 1...4
the power class to be evaluated
Parameters:
<State> ON | OFF
*RST: OFF
Example:
CALC:LIM:ESP:PCL1 ON
Activates the first defined power class.
Manual operation: See "Used Power Classes" on page 266
See "Add/Remove" on page 267
CALCulate<n>:LIMit<k>:ESPectrum:PCLass<Class>:LIMit[:STATe] <State>
This command defines which limits are evaluated in the measurement.
Suffix:
<n>
.
irrelevant
<k> irrelevant
<Class> 1...4
the power class to be evaluated
Parameters:
<State> ABSolute | RELative | AND | OR
