Quick Start
R&S
®
ESR
79User Manual 1175.7068.02 ─ 12
sign key (-) toggles between capital and small letters. For the assignment refer to
Table 3-3.
Entering numbers and (special) characters via the keypad
1. Press the key once to enter the first possible value.
2. All characters available via this key are displayed.
3. To choose another value provided by this key, press the key again, until your
desired value is displayed.
4. With every key stroke the next possible value of this key is displayed. If all possible
values have been displayed, the series starts with the first value again. For infor-
mation on the series refer to Table 3-3.
5. To change from capital to small letters and vice versa, press the sign key (-).
6. When you have chosen the desired value, wait for 2 seconds (to use the same key
again), or start the next entry by pressing another key.
Entering a blank
► Press the "Space" bar, or press the "0" key and wait 2 seconds.
Correcting an entry:
1. Using the arrow keys, move the cursor to the right of the entry you want to delete.
2. Press the [BACKSPACE] key.
3. The entry to the left of the cursor is deleted.
4. Enter your correction.
Completing the entry
► Press the [ENTER] key or the rotary knob.
Aborting the entry
► Press the [ESC] key.
The dialog box is closed without changing the settings.
Table 3-3: Keys for alphanumeric parameters
Key name
(upper inscription)
Series of (special) characters and number provided
7 7 µ Ω ° € ¥ $ ¢
8 A B C 8 Ä ÆÅ Ç
9 D E F 9 É
Basic Operations
