R&S ESR Series User Manual

Remote Control
R&S
®
ESR
838User Manual 1175.7068.02 ─ 12
Suffix:
<n>
.
irrelevant
Parameters:
<TriggerLevel> Range: 0.5 V to 3.5 V
*RST: 1.4 V
Example:
TRIG:LEV 2V
TRIGger<n>[:SEQuence]:LEVel:IFPower <TriggerLevel>
This command defines the power level at the third intermediate frequency that must be
exceeded to cause a trigger event. Note that any RF attenuation or preamplification is
considered when the trigger level is analyzed. If defined, a reference level offset is also
considered.
Suffix:
<n>
.
irrelevant
Parameters:
<TriggerLevel> *RST: -20 dBm
Example:
TRIG:LEV:IFP -30DBM
Manual operation: See "Trg/Gate Level" on page 377
See "Trigger Level" on page 472
TRIGger<n>[:SEQuence]:LEVel:RFPower <TriggerLevel>
This command defines the power level at the third intermediate frequency that must be
exceeded to cause a trigger event. Note that any RF attenuation or preamplification is
considered when the trigger level is analyzed. If defined, a reference level offset is also
considered.
Suffix:
<n>
.
irrelevant
Parameters:
<TriggerLevel> *RST: -20 dBm
Example:
TRIG:LEV:RFP -30dBm
TRIGger<n>[:SEQuence]:LEVel:VIDeo <Value>
This command sets the level of the video trigger source.
Suffix:
<n>
.
irrelevant
Parameters:
<Value> 0 to 100 PCT
*RST: 50 PCT
Example:
TRIG:LEV:VID 50PCT
Remote Commands in Spectrum Analyzer Mode
