R&S ESR Series User Manual

Remote Control
R&S
®
ESR
837User Manual 1175.7068.02 ─ 12
Parameters:
<Delay> Range: zero span: -sweeptime (see data sheet) to 30 s;
span: 0 to 30 s
*RST: 0 s
Example:
TRIG:HOLD 500us
Manual operation: See "Trigger Offset" on page 378
TRIGger<n>[:SEQuence]:IFPower:HOLDoff <Value>
This command sets the holding time before the next IF power trigger event.
Note: Using gating with gate mode "level" (see TRACe<n>:IQ:EGATe:TYPE
on page 897) and an IFP trigger (see TRIGger<n>[:SEQuence]:LEVel:IFPower
on page 838), the holdoff time for the IFP trigger is ignored for frequency sweep, FFT
sweep, zero span and IQ mode measurements.
Suffix:
<n>
.
irrelevant
Parameters:
<Value> *RST: 150 ns
Example:
TRIG:SOUR IFP
Sets the IF power trigger source.
TRIG:IFP:HOLD 200 ns
Sets the holding time to 200 ns.
Manual operation: See "Trigger Holdoff" on page 378
TRIGger<n>[:SEQuence]:IFPower:HYSTeresis <Value>
This command sets the limit that the hysteresis value for the IF power trigger has to fall
below in order to trigger the next measurement.
Suffix:
<n>
.
irrelevant
Parameters:
<Value> *RST: 3 dB
Example:
TRIG:SOUR IFP
Sets the IF power trigger source.
TRIG:IFP:HYST 10DB
Sets the hysteresis limit value.
Manual operation: See "Trigger Hysteresis" on page 378
TRIGger<n>[:SEQuence]:LEVel[:EXTernal] <TriggerLevel>
This command sets the level of the external trigger source in Volt.
Remote Commands in Spectrum Analyzer Mode
