R&S ESR Series User Manual

Remote Control
R&S
®
ESR
897User Manual 1175.7068.02 ─ 12
Parameters:
<Samples> <numeric value>
Max = MaxPreTriggerSamples * 128 MHz/sample rate
pretrigger samples defined by TRACe<n>:IQ:SET;
sample rate defined by TRACe<n>:IQ:SRATe)
Range: 1...Max (samples)
*RST: 100
Example:
TRAC:IQ:EGAT:GAP 2
TRACe<n>:IQ:EGATe:LENGth <GateLength>
Defines the gate length in samples in edge mode. For details see Chapter 11.6.2, "I/Q
Gating", on page 899.
Suffix:
<n>
.
irrelevant
Parameters:
<GateLength> <numeric value>
Max = MaxPreTriggerSamples * 128 MHz/sample rate
pretrigger samples defined by TRACe<n>:IQ:SET;
sample rate defined by TRACe<n>:IQ:SRATe)
Range: 1...Max (samples)
*RST: 100
Example:
TRAC:IQ:EGAT:LENG 2000
TRACe<n>:IQ:EGATe:NOFgateperiods <Number>
Defines the number of gate periods after a trigger signal. For details see Chap-
ter 11.6.2, "I/Q Gating", on page 899.
Suffix:
<n>
.
irrelevant
Parameters:
<Number> 1...1023
*RST: 1
Example:
TRAC:IQ:EGAT:NOF 2
TRACe<n>:IQ:EGATe:TYPE <Type>
Specifies the gate trigger type used for data collection. For details see Chapter 11.6.2,
"I/Q Gating", on page 899.
Note: Using gating with gate mode "level" and an IFP trigger ( TRIGger<n>[:
SEQuence]:SOURce), the holdoff time for the IFP trigger (see TRIGger<n>[:
SEQuence]:IFPower:HOLDoff on page 837) is ignored.
Remote Commands in I/Q Analyzer Mode
