Working with the Soft Front Panel

Basic operation with the soft Front Panel is identical to normal operation. To activate a

key, either press the key on the touchscreen, or click on it with the mouse pointer. To

simulate the use of the rotary knob, use the additional keys displayed between the key-

pad and the arrow keys:

Icon Function

Turn left

Enter

Turn right

Switching to Mini Front Panel display

1. Press the [DISPLAY] key.

2. In the "Display Settings" dialog box, select "Mini Front Panel State: On".

The "Mini Front Panel" window appears on the screen. It can be moved anywhere

on the screen where it does not interfere with your current task.

Using the key combination [ALT + M] you can toggle the Mini Front Panel display on

and off.
