R&S ESR Series User Manual

Remote Control
R&S
®
ESR
932User Manual 1175.7068.02 ─ 12
ON | 1
User port is switched to INPut
OFF | 0
User port is switched to OUTPut
*RST: 1
Manual operation: See "User Port" on page 187
INPut<ip>:UPORt[:VALue]
This command queries the control lines of the user ports.
For details see OUTPut:UPORt[:VALue] on page 933.
Suffix:
<ip>
.
1 | 2
irrelevant
Example:
INP:UPOR?
//Result: #B00100100
Pins 5 and 7 are active.
Manual operation: See "User Port" on page 187
OUTPut:IF[:SOURce] <Source>
This command selects the source of the IF output.
Parameters:
<Source> IF
Outputs the intermediate frequency.
OFF
Turns off the output of a signal.
VIDeo
Outputs the video signal (200 mV).
*RST: IF
Example:
OUTP:IF VID
Selects the video signal for the IF output connector.
Manual operation: See "Video Output" on page 384
OUTPut:TRIGger <PortLevel>
This command selects level of the Trigger Out port. Thus, you can trigger an additional
device via the external trigger port, for example.
Parameters:
<PortLevel> LOW | HIGH
*RST: LOW
Example:
OUTP:TRIG HIGH
System Configuration
