8.3 BY-PASS FEED
8.3.1 By-pass Feed Table Mechanism
The by-pass feed table switch [A] detects when the by-pass feed table is
opened. Then the CPU turns on the by-pass feed indicator on the operation
panel.
The by-pass feed table can hold up to 40 sheets of (20lb bond) paper.
[A]
Detailed
Section
Descriptions
PAPER FEED AND REGISTRATION
SM 2-119 A166/A187/A189
