Ricoh A66 - SP5-804 Output Check

1.3.7 SP5-804 Output Check
To activate the electrical component, press the start key. To stop the
electrical component, press the clear modes key.
NOTE: After pressing the start key, the machine displays "Result =01 (#)".
After that, press the

key, and the display goes back to the menu
display. When the clear/stop key is pressed, the electrical
component stops and the machine displays "Result=00 (#)". Then
press the

key to go back to the menu display.
To check another component, use the

key or key to change the
display.
NOTE: The motors keep turning in this output mode regardless of inputs
from sensors.
To prevent mechanical or electrical damage, do not keep the
electrical component on for a long time.
SP No.
Display Electrical Component/Mode
1st 2nd 3rd
5 804 1 OUT:Paper Feed Clutch Paper Feed Clutch
5 804 2 OUT:Relay Clutch Relay Cluch
5 804 3 OUT:By-ps Feed Clutch By-pass Feed Clutch
5 804 4 OUT:By-ps Pck-upSOL: Mn By-pass Pick-up Solenoid: Main
5 804 5 OUT:Charge Corona/Grid 1 Charge Corona Grid 1
5 804 6 OUT:Charge Corona/Grid 2 Charge Corona Grid 2
5 804 7 OUT:Charge Corona/Grid 3 Charge Corona Grid 3
5 804 8 OUT:Development Bias:AC Development Bias: AC
5 804 9 OUT:Development Bias:DC Development Bias: DC
5 804 10 OUT:Dev Bias:AC+DC Development Bias: AC+DC
5 804 11 OUT:Belt Trans Crnt Belt Transfer Current
5 804 12 OUT:Paper Trans Crnt Paper Transfer Current
5 804 13 OUT:Separation Crnt Paper Separation Current
5 804 14 OUT:Toner Sply Motor Toner Supply Motor
5 804 15 OUT:Charge Inlet Fan Charge Inlet Fan
5 804 16 OUT:Quenching Lamp Quenching Lamp
5 804 17 OUT:ID Sensor LED ID Sensor LED
5 804 18 OUT:Belt Cleaning SOL Belt Cleaning Solenoid
5 804 19 OUT:Lubricant Brush SOL Lubricant Brush Solenoid
5 804 20 OUT:Main Motor: Normal Main Motor: Normal Speed
5 804 21 OUT:Main Motor: Half Main Motor: Half Speed
5 804 22 OUT:Drum Motor: Normal Drum Motor: Normal Speed
5 804 23 OUT:Drum Motor: Half Drum Motor: Half Speed
5 804 24 OUT:Dev Motor:Normal Development Motor: Normal Speed
5 804 25 OUT:Dev Motor:Half Development Motor: Half Speed
5 804 26 OUT:Toner Supply SOL Toner Supply Solenoid
5 804 27 OUT:Revolver Drive Motor Revolver Drive Motor: 1/4 Rotation
5 804 28 OUT:Transport Fan Transport Fan
Service
Tables
SERVICE PROGRAM MODES
SM 4-7 A166/A187/A189
