SP No.
Display Electrical Component/Mode
1st 2nd 3rd
5 804 29 OUT:Optics Cooling Fan 1 Optics Cooling Fan 1
5 804 30 OUT:Optics Cooling Fan 2 Optics Cooling Fan 2
5 804 32 OUT:Exposure Lamp Exposure Lamp
5 804 33 OUT:Scanner Motor Crnt Scanner Motor Current
5 804 34 OUT:Fusing Exhaust Fan 1 Fusing Exhaust Fan 1
5 804 35 OUT:Fusing Exhaust Fan 2 Fusing Exhaust Fan 2
5 804 36 OUT:Junction Gate SOL Duplex Junction Gate Solenoid
5 804 37 OUT:Total Counter Total Counter
5 804 38 OUT:Polygon Motor Polygon Motor
5 804 39 OUT:Dplx Motor: Forward Duplex Motor: Forward
5 804 40 OUT:Dplx Motor: Reverse Duplex Motor: Reverse
5 804 41 OUT:Jggr Side Fence Mtr Jogger Side Fence Motor
5 804 42 OUT:Jggr End Fence Mtr Jogger End Fence Motor
5 804 43
OUT:Ptnl Sn Calib TRG Drum Potential Sensor Calibration
Trigger
5 804 44 OUT:Main Power Relay Main Switch Relay
5 804 45 OUT:Fusing Lamp Fusing Lamp
5 804 46 OUT:Pressure Roller Lamp Pressure Roller Lamp
5 804 47 OUT:Scanner Fan 1,2 Optics Coding Fan 1, 2
5 804 48 OUT:Scanner Fan 3 Optics Exhaust Fan
5 804 49 OUT:Scanner Fan 4 Scanner Board Cooling Fan
5 804 50 OUT:Registration Clutch Registration Clutch
5 804 51 OUT:Ppr Tr Rev Current Paper Transfer Reverse Current
5 804 52 OUT:PTL Pre-transfer Lamp
5 804 53 OUT:By-ps Pck-up SOL:Sub By-pass Pick-up Solenoid: Sub
5 804 54
OUT:Reverse Crnt Relay Reverse Current Relay for Paper
Transfer Charge Unit
SERVICE PROGRAM MODES
A166/A187/A189 4-8 SM
