7.2.2 Belt Cleaning Solenoid Replacement
1. Remove the cleaning unit bottom cover [A] (6 latches).
2. Remove the spring [B] (1 spring).
3. Remove the belt cleaning solenoid [C] (2 screws and 1 connector).
NOTE: When turning the cleaning unit upside-down, be careful of the toner
that will spill out.
[A]
[C]
[B]
TRANSFER BELT UNIT
A166/A187/A189 5-54 SM
