Ricoh A66 - Lubricant Solenoid Replacement

7.4.2 Lubricant Solenoid Replacement
1. Remove the right front cover and the right cover (see procedure 1.7).
2. Remove the lubricant solenoid bracket [A] (2 screws and 1 connector).
3. Remove the lubricant solenoid [B] (2 screws).
[A]
[B]
TRANSFER BELT UNIT
A166/A187/A189 5-58 SM
