Ricoh A66 - Motors

4.7 MOTORS
1
8
9
10
7
6
5
4
3
2
1. Toner Supply Motor
2. Scanner Motor
3. Revolver Drive Motor
4. Development Drive Motor
5. Polygon Motor
6. Drum Motor
7. Main Motor
8. Duplex Feed Motor
(A187/A189 only)
9. Side Fence Jogger Motor
(A187/A189 only)
10. End Fence Jogger Motor
(A187/A189 only)
PARTS LAYOUT
A166/A187/A189 1-22 SM
