Ricoh A66 - Upper Covers

1.5 UPPER COVERS
1. Remove the right upper bracket [A] (1 screw).
2. Remove the left upper bracket [B] (1 screw).
3. Remove the front upper cover [C] (2 screws).
4. Remove the upper right cover [D] (2 screws).
5. Remove the upper left cover [E] (2 screws).
6. Remove the upper rear cover [F] (2 screws).
[A]
[B]
[C]
[D]
[E]
[F]
Replacement
and
Adjustment
EXTERIOR
SM 5-3 A166/A187/A189
