Ricoh A66 - Left Covers; Right Covers

1.7 RIGHT COVERS
1. Remove the right rear cover [A] (2 screws).
2. Open the bypass tray [B].
3. Remove the right front cover [C] (1 screw and 2 hooks).
4. Remove the right cover [D] (4 screws).
1.8 LEFT COVERS
1. Remove the upper cover [E] (2 screws).
2. Remove the left front cover [F] (1 screw and 2 hooks).
3. Remove the left cover [G] (4 screws).
[E]
[F]
[G]
[A]
[B]
[C]
[D]
Replacement
and
Adjustment
EXTERIOR
SM 5-5 A166/A187/A189
