2. COMPONENT LAYOUT
2.1 MECHANICAL COMPONENT LAYOUT
1. Paper Tray 1
2. Pick-up Roller
3. Paper Feed Roller
4. Relay Rollers
5. Reverse Roller
6. Lower Right Door
7. Paper Lift Motors
8. Paper Tray 3 (A549 model only)
9. Paper Tray 2
1
2
3
4
5
6
7
8
9
COMPONENT LAYOUT
A166/A187/A189 8-2 SM
