6.2 INSTALLATION PROCEDURE
CAUTION
Unplug the copier power cord before starting the following procedure.
Do not lift the sorter stapler by holding the entrance guide [A].
Otherwise, the resulting damage may cause paper jams to occur.
1. Remove the strips of tape.
2. Remove the cardboard pieces [B] and the foam blocks [C].
[A]
Incorrect Lifting Method
[B]
[C]
[C]
[B]
[C]
[B]
Installation
Procedure
10-BIN SORTER (A555) INSTALLATION
SM 3-47 A166/A187/A189
