9.4.2 Junction Gate Mechanism (A187/A189 copiers only)
The junction gate [A] changes the direction of the paper coming out of the
fusing unit to the copy tray or to the duplex unit. The junction gate is
controlled by switching the junction gate solenoid [B].
•
To the copy tray: junction gate solenoid off
•
To the duplex unit: junction gate solenoid on
[A]
[B]
To the copy
tray
ON
OFF
To the duplex unit
PAPER TRANSPORT AND IMAGE FUSING
A166/A187/A189 2-132 SM
