1.3.14 SP6-903 Sorter Input Check
SP No.
Display Sensor/Switch /Signal
Status
1st 2nd 3rd 0 1
6 903 1 IN:No(10)/Entrance(3) Not used – –
6 903 2 IN:No(10)/1st Bin(3) Not used – –
6 903 3
IN:Entry(10)/2nd Bin(3) Sorter Entrance Sensor
No Paper
Paper
present
6 903 4
IN:Bin(10)/3rd Bin(3) Bin Sensor
No Paper
Paper
present
6 903 5 IN:Bin HP/Lift L-Limit Bin H.P. Sensor Not H.P. H.P.
6 903 6 IN:Bin Pos.(10)/No(3) Wheel Sensor Not Detect Detect
6 903 7 IN:Jggr HP/Shift Pos Jogger H.P. Sensor Not H.P. H.P.
6 903 8 IN:Chuck HP(10)/No(3) Grip H.P. Sensor Not H.P. H.P.
6 903 9
IN:Stapler
HP(10)/No(3)
Stapler H.P. Sensor
Not H.P. H.P.
6 903 10
IN:Staple
End(10)/No(3)
Stapler End Sensor
Stapler
Present
Stapler End
6 903 11
IN:Ppr Sen(10)/Ppr
Sen 3
Stapler Paper Sensor
No Paper
Paper
Present
6 903 12 IN:Door Safety Switch Door Safty Switch Closed Open
6 903 13
IN:SS
Encorder(10)/No(3)
Timing Sensor
OFF ON
6 903 14 IN:No(10)/Turn:(3) Not Used – –
1.3.15 SP6-904 Sorter Output Check
SP No.
Display
Electrical
Component
1st 2nd 3rd
6 904 1 OUT:SS Mn Mtr10/Mn Mtr 3 Transport Motor
6 904 2 OUT:No(10)/Exit Motor(3) Not used
6 904 3 OUT:No(10)/Switch SOL(3) Not used
6 904 4 OUT:Bin Lift M./Lift M. Bin Drive Motor
6 904 5 OUT:Jggr Mtr(10)/No(3) Jogger Motor
6 904 6 OUT:Chuck Mtr(10)/No(3) Grip Motor
6 904 8 OUT:No(10)/Turn SOL(3) Not used
6 904 9 OUT:No(10)/2nd Bin SOL 3 Not used
6 904 10 OUT:No(10)/3rd Bin SOL 3 Not used
