4.3 PCB (A189 COPIER)
20
23
21
22
19
19. SCU Board
20. Operation Panel
21. Extended IPU Board
22. Duplex Control Board
23. RAM Board
PARTS LAYOUT
A166/A187/A189 1-18 SM
