Ricoh A66 - Oil Supply Pad Replacement

9.4 OIL SUPPLY PAD REPLACEMENT
1. Remove the fusing unit (see procedure 9.3)
2. Remove the fusing unit top cover [A] (1 screw).
3. Remove and replace the oil supply pad [B] (4 screws).
[A]
[B]
Replacement
and
Adjustment
PAPER TRANSPORT AND FUSING
SM 5-75 A166/A187/A189
