2.2 DRIVE LAYOUT
1. Vertical Transport Roller Gears
2. Paper Feed Clutch 1
3. Paper Feed Clutch 2
4. Separation Roller Gears
5. Paper Feed Clutch 3
6. Main Motor
7. Relay Clutch
8. Timing Pulley
1
2
1
3
4
5
6
7
8
4
4
A549V503.img
PAPER TRAY
UNIT
PS290/PS280
(A549/A550
COMPONENT LAYOUT
SM 8-3 A166/A187/A189
