8. FILM PROJECTOR UNIT (A718)
INSTALLATION
8.1 ACCESSORY CHECK
Make sure that each accessory listed in the following table is in the box. Also
check the condition of each item.
1. Mirror Unit........................................................................... 1
2. Power Cord......................................................................... 1
3. Optical Fiber Cable............................................................. 1
4. Film Strip Holder................................................................. 1
5. Slide Holder ........................................................................ 1
6. Glass Mount Holder............................................................ 1
7. Base Film (FUJI, KODAK, AGFA)...................................... 3
8. Slide Mount......................................................................... 1
9. Correction Filter (P, N)........................................................ 2
10. Blower Brush ...................................................................... 1
11. Projection Lamp.................................................................. 1
12. Film Position Sheet............................................................. 2
13. Positioning Pin.................................................................... 2
14. Spacer ................................................................................ 4
15. Philips Pan Head Screw - M4 x 8....................................... 2
16. Philips Pan Head Screw - M4 x 12..................................... 4
17. Installation Procedure......................................................... 1
18. New Equipment Condition Report 1 (-17/-27 only)............. 1
Installation
Procedure
FILM PROJECTOR UNIT (A718) INSTALLATION
SM 3-53 A166/A187/A189
