Installation Procedure of Language ROM
NOTE:
•
The following procedure given by sub-steps numbered (1) through
(6) are required only for A166-26,27, A187-26,27 and
A189-26,27 copiers.
•
These procedure should be done between step 3. and 4. of the
copier installation.
(1) Remove the right upper bracket [a] (1 screw).
(2) Remove the left upper bracket [b] (1 screw).
(3) Remove the front upper cover [c] (2 screws).
(4) Remove the operation panel [d] (4 screws).
[a]
[c]
[b]
[d]
COPIER INSTALLATION
A166/A187/A189 3-8 SM
