A
Drum Unit
Removal
Drum Unit
Reinstallation
Transfer Belt Unit
Reinstallation
Dev. Unit
Reinstallation
B
Toner Cartridge
Installation
(Bk, C, M, Y)
Outer Cover/Inner
Cover
Reinstallation
Remove the following parts:
1. Charge Corona Unit
2. Drum Stay
3. Drum Securing Spring
4. Drum Protective Sheet
5. Drum Cleaning Blade Release
Wedge
Remove the Toner Cartridge Shutters.
Reinstall the following parts:
1. Used Toner Tank
2. Transfer Belt Fan
3. Developer Supply Funnel/Collection
Bottle
4. Development Roller Rotation Handle
Reinstall the following parts:
1. Right Cover/Right Front Cover
2. Inner Cover/Front Door
Installation
Procedure
INSTALLATION PROCEDURE FLOWCHART
SM 3-37 A166/A187/A189
To Next Page
