3. Install the transfer belt release wedges [A] (1 screw for each).
4. Install the transfer belt retainer [B] (1 screw).
5. Install the revolver stopper [C] (1 screw).
[A]
[B]
[C]
OTHERS
A166/A187/A189 3-64 SM
