SP No.
Display Sensor/Switch/Signal
Status
1st 2nd 3rd 0 1
5 803 12 IN:Main Mtr Lck Detect
Main Motor
Syncronization Signal
Detection
Detect
(Motor
Rotation)
Not
Detect
(No
Rotation)
5 803 13 IN:Drum Mtr Lck Detect
Drum Motor
Syncronization Signal
Detection
Not
Detect
(No
Rotation)
Detect
(Motor
Rotation
5 803 14 IN:Dev Dr Mtr Lck Detect
Development Drive
Motor Syncronization
Signal Detection
Not
Detect
(No
Rotation)
Detect
(Motor
Rotation)
5 803 15 IN:Front Door SW Front Door Switch Closed Open
5 803 16 IN:Oil End Sensor Oil End Sensor Not End End
5 803 17 IN:Toner Overflow Sn Toner Overflow Sensor OFF ON
5 803 18 IN:Duplex Unit Set Sn Duplex Unit Set Sensor Not Set Set
5 803 19 IN:Jggr Side Fence HP Sn
Jogger Side Fence
Home Position Sensor
Not
H.P.
H.P.
5 803 20 IN:Jggr End Fence HP Sn
Jogger End Fence
Home Position Sensor
Not
H.P.
H.P.
5 803 21 IN:Dplx Paper End Sn
Duplex Paper End
Sensor
Paper
present
Paper
end
5 803 22 IN:Dplx Entrance Sn
Duplex Entrance
Sensor
No
paper
Paper
present
5 803 23 IN:Duplex Turn Sn
Duplex Turn Sensor No
paper
Paper
present
5 803 24 IN:Scanner HP Sensor
Scanner Home
Position Sensor
Not
H.P.
H.P.
5 803 25 IN:Platen Position Sn
Platen Position Sensor Cover
open
Closed
5 803 26 IN:Exp. Lamp ON Signal Lamp ON Signal OFF ON
5 803 27 IN:Toner Cartridge Sn: K
Bk Toner Cartridge
Sensor
Not
Detect
Detect
5 803 28 IN:Tnr Cartridge Sn:CMY
Color Toner Cartridge
Sensor
Not
Detect
Detect
5 803 29 IN:IDU Unit
IDU Unit Not
Installed
Installed
5 803 30 IN:Paper Exit Door SW Paper Exit Door Switch Closed Open
5 803 31 IN:Poly. Mtr Lck Detect
Polygon Motor
Synchronization Signal
Detection
Not
H.P.
H.P.
5 803 32 IN:AC Detection
AC Detection Not
H.P.
H.P.
Service
Tables
SERVICE PROGRAM MODES
SM 4-5 A166/A187/A189
