SP6-901-1 to 3– (Check Paper Size)
Metric version Inch version
1A3 A3
2B4 B4
3 A4 sideways A4 sideways
4 A4 lengthwise A4 lengthwise
5 B5 sideways –
6 B5 lengthwise –
7 A5 sideways A5 sideways
8 11" x 17" 11" x 17"
9– 8
1/2
" x 14"
10 8
1/2
" x 11" 8
1/2
" x 11"
11 11" x 8
1/2
" 11" x 8
1/2
"
12 8
1/2
" x 5
1/2
"8
1/2
" x 5
1/2
"
13 8" x 13" 8" x 13"
14 8
1/2
" x 13" 8
1/2
" x 13"
15 8
1/4
" x 13" 8
1/4
" x 13"
16 – 11" x 15"
17 – 10" 14"
18 – 8" x 10
1/2
"
19 8" x 10" 8" x 10"
20
8K (267 mm x 390 mm/
lengthwise)
–
21
16K (267 mm x 195 mm/
lengthwise)
–
22
16K (195 mm x 267 mm/
sideways)
–
–
**
SP6-901-7– (Paper Feed Sensor Check)
Relay
Sensor 1
Relay
Sensor 2
Relay
Sensor 3
Displayed
Number
No Paper No Paper No Paper 0
Paper
preset
No Paper No Paper 1
No Paper
Paper
Present
No Paper 2
Paper
Present
Paper
Present
No Paper 3
No Paper No Paper
Paper
Present
4
Paper
Present
No Paper
Paper
Present
5
No Paper
Paper
Present
Paper
Present
6
Paper
Present
Paper
Present
Paper
Present
7
Service
Tables
