1st 2nd 3rd Display Function
Default,
( ): For Europe
Settings/Range Comments Report
PAPER FEED/TRANSPORT/FUSING
1 1 1 Lead Edge Regist.:Nrml Shifts the vertical image position
by changing the ON timing of the
registration clutch for each paper
type.
0 -5.0 to +5.0 (mm) See "Replacement and
Adjustment: Copy Image
Adjustments" for how to use
these SP modes.
Bank 1: Top tray of the
optional paper feed unit
Bank 2: 2nd tray of the
optional paper feed unit
Bank 3: 3rd tray of the
optional paper feed unit
(three-tray types only)
P
1 1 2 Lead Edge Regist:OHP/Thk 0 -5.0 to +5.0 (mm)
P
1 2 1 Side to Side Reg: By-ps
Adjusts the horizontal image
position by changing the main
scanning start position for each
paper feed station.
0 -5.0 to +5.0 (mm)
P
1 2 2 Side to Side Reg: Tray 0 -5.0 to +5.0 (mm)
P
1 2 3 Side to Side Reg: Bank-1 0 -5.0 to +5.0 (mm)
P
1 2 4 Side to Side Reg: Bank-2 0 -5.0 to +5.0 (mm)
P
1 2 5 Side to Side Reg: Bank-3 0 -5.0 to +5.0 (mm)
P
1 2 6 Side to Side Reg: Dplx 0 -5.0 to +5.0 (mm)
P
1 3 1 P.Feed Tmg: Nrml/By-ps Changes the paper feed clutch on
period at each feed station to
adjust the paper buckle at the
registration roller for each paper
type.
0 -5.0 to +5.0 (mm)
P
1 3 2 P.Feed Tmg: Nrml/Tray 0 -5.0 to +5.0 (mm)
P
1 3 3 P.Fd.Tmg: OHP/Thk/By-ps 0 -5.0 to +5.0 (mm)
P
1 3 4 P.Feed Tmg:Dplx
Changes the paper feed clutch on
period at the duplex tray to adjust
the paper buckle at the
registration roller.
0 -5.0 to +5.0 (mm)
P
1 8 Jam Detection OFF
Specifies whether the jam sensors
work or not.
0 0: ON, 1: OFF Use for testing only.
P
1 101 Oil End Sensor
Specifies whether the oil end
sensor is installed or not.
1 0: No, 1: Yes Do not change the setting.
P
1 104 Fusing Control
Selects the fusing temperature
control mode
0 0: ON/OFF, 1: Phase
Phase control mode should
only be selected if the user
has a problem with electrical
noise or interference.
P
PAPER FEED/TRANSPORT/FUSING
SM APPENDIX 11-20 A166/A187/A189
