OfficeServ 7100 PROGRAMMING
TECHNICAL MANUAL PART 2 APRIL 2007
MMC: 504 PULSE MAKE/BREAK RATIO
DESCRIPTION:
Allows the ability to change the value of pulses per second and the duration of the
make/break time. This will only affect rotary dial trunks.
FEATURE KEYS
Dial 0 Make/Break Ratio (01–99)
Dial 1 Pulse Per Second (10 or 20)
PROGRAM KEYS
UP & DOWN Used to scroll through options
KEYPAD Used to enter selections
SOFT KEYS Move cursor left and right
SPEAKER Used to store data and advance to next MMC
ACTION DISPLAY
1. Press TRANSFER 504.
Display shows.
MAKE/BREAK RATIO
33 MAKE→
2. Dial 0 or 1 for option
OR
PULSE PER SECOND
10 PPS →_
Press UP or DOWN key for selection and
press RIGHT soft key to move cursor.
3. Dial new value.
System returns to step 2.
PULSE PER SECOND
10 PPS →20
4. Press TRANSFER to store and exit
OR
Press SPEAKER to store and advance to next
MMC.
DEFAULT DATA: MAKE/BREAK = 33
PULSES PER SECOND = 10
RELATED ITEMS: MMC 402 TRUNK DIAL TYPE
